Carton Bale Press Machine
Machine Photo
It is widely used for compression and baling packaging carton printing paper mill food garbage recycling and other industries.
● Adopting the left and right shrinking method through the oil cylinder automatic and manual tightening and relaxation easy to adjust.
● Left -right compressing and pushing bale out the length of bale can be adjusted pushing out bale continuously to improve work efficiency.
● PLC program control electric button control simple operation with feeding detection and automatic compression.
● The baling length can be set and there are bundling reminders and other devices.
● The size and voltage of the bale can be customized according to the reasonable requirements of the customer. The weight of the bale is different for different packaging materials.
● Three-phase voltage safety interlock simple operation can be equipped with air pipe and conveyor feeding material with higher efficiency.
| Model | LQJPW40E | LQJPW60E | LQJPW80E |
| Compression Force | 40ton | 60ton | 80ton |
| Bale Size (WxHxL) | 720x720 x(500-1300)mm |
750x850 x(500-1600)mm |
1100x800 x(500-1800)mm |
| Feed Opening Size (Lxw) | 1000x720mm | 1200x750mm | 1500x800mm |
| Bale Line | 4lines | 4lines | 4lines |
| Bale Weight | 200-400kg | 300-500kg | 400-600kg |
| Power | 11Kw/15Hp | 15Kw/20Hp | 22Kw/30Hp |
| Capacity | 1-2ton/hour | 2-3ton/hour | 4-5ton/hour |
| Out Bale Way | Continuously push bale | Continuously push bale | Continuously push bale |
| Machine Size (Lxwxh) | 4900x1750x1950mm | 5850x1880x2100mm | 6720x2100x2300mm |
| Model | LQJPW100E | LQJPW120E | LQJPW150E |
| Compression Force | 100ton | 120ton | 150ton |
| Bale Size (WxHxL) | 1100x1100 x(500-1800)mm |
1100x1200 x(500-2000)mm |
1100x1200 x(500-2100)mm |
| Feed Opening Size (LxW) | 1800x1100mm | 2000x1100mm | 2200x1100mm |
| Bale Line | 5lines | 5lines | 5lines |
| Bale Weight | 700-1000kg | 800-1050kg | 900-1300kg |
| Power | 30Kw/40Hp | 37Kw/50Hp | 45Kw/61Hp |
| Capacity | 5-7ton/hour | 6-8ton/hour | 6-8ton/hour |
| Out Bale Way | Continuously push bale |
Continuously push bale |
Continuously push bale |
| Machine Size (LxWxH) | 7750x2400x2400mm | 8800x2400x2550mm | 9300x2500x2600mm |
● We take pride in our ability to produce top-quality Semi Automatic Baler products at affordable prices.
● After years of unremitting efforts and pursuits, adhering to the corporate tenet of 'Quality, Speed, Service', we can provide excellent services to new and old customers.
● We have a wide range of Semi Automatic Baler products to choose from, ensuring that customers can find what they need.
● Our company has developed in the Horizontal Baler industry for many years. We hope to continue to improve our processing technology and research and development of related products because we believe that only by improving the technological content and strengthening the quality awareness can the world love our products.
● Our factory has a proven track record of producing reliable and durable Semi Automatic Baler products.
● We provide high-quality and efficient cargo tracking services to greatly improve efficiency for customers.
● Our Semi Automatic Baler products are backed by a comprehensive warranty and maintenance program.
● We adhere to the concept of putting talents in the most suitable position, constantly learn to challenge ourselves, and make the best use of our talents.
● Our experienced technicians ensure that each Semi Automatic Baler product meets the highest quality standards.
● With a proven track record of long-term reliable service, our company has established close relationships with a number of well-known companies.
